Technical Specification
AirSentric™️ PD29
Motion Sensor
Motion Range
3.65 m (12 ft)
Motion Output
0 - 100
Motion Resolution
1
Light Level
Ambient Light Output
0 - 88,000 lux
Accuracy
(at –10 to 85 °C) ± 0.3 °C (typical)
Stability
< 0.01 °C/Y
Sound Level
Sound Level Range
30 – 130 dBA
Sound Sensor Accuracy
+/- 1.5 dBA
Temperature Sensor
Temperature range
0 to 50°C
Accuracy
(at –10 to 85 °C) ± 0.3 °C (typical)
Stability
< 0.01 °C/Yr
Humidity Sensor
Humidity range
5 to 95 % RH continuous
Accuracy
(at 0 – 90 % RH) ± 5 % RH (max)
Stability
< 0.25 % RH/Yr
Size & Weight
Size
Size (LxWxD) – 4 in (100 mm) x 6 in (150 mm) x 1.8 in (45 mm)
Weight
320 g (enclosure weight without power adapter)
Connectivity
Zigbee
GY36 Zigbee to Ethernet Gateway, 2.4 GHz, up to 30 m range
Wi-Fi
802.11 b/g (optional subject to MOQ)
Power
Power Supply
100 - 240 V International Adapter, DC 12 V +/- 10 %, 420 mA
Power Cable
2 metres
Power Consumption
250 mA @ 12 V
Power over Ethernet
PoE option available
Operating Temperature
Range
0°C to 50°C (32 F to 122 F)
Accessories
Mounting
Wall mount bracket supplied
Elbow connector
Extended elbow connector (2 metres) – optional
Software
User interface
HEX cloud-based account
Compliance / Certification
Accreditation
RESET Air accredited
Compliance
CE, FCC, RoHS
